Automatic tempering machine 30 kg

12.900 €
Free consultation

Our website is not an online-store. It's online-catalog. Manager will contact you to clarify a cost of delivery and payment methods after you place your order.

The minimum order amount is 200 €

Description

Compact and effective automatic tempering machine for chocolate with a load capacity up to 30 kg. High performance and fast results — this model tempers 30 kg in about 15 minutes, so it’s able to temper up to 90 kg of chocolate in an hour.

The machine is designed the way the chocolate is always in a pre-crystallized (tempered) state, circulating in a loop. The chocolate temperature in the tank is 45ºC. Cooling happens at a specific point in the flow inside the machine, which creates a seed for the tempering. When leaving the machine the chocolate is 31ºC. Over-crystallization can't happen under such conditions and the chocolate stability is maintained.

Features:

  • Reliable analog control system;
  • High speed of chocolate dissolving;
  • Chocolate flow control via handy volumetric dispenser with a pedal;
  • Built-in cooling system;
  • Compact;
  • Low-voltage vibrating table included.
Video
The appearance of goods and packaging may differ from the video.
Specifications
Dimensional size 838 х 960 х 1474 mm
Weight 185 kg
Productive capacity 90 kg / hour
Loading capacity 30 kg
Supply 380 V (220 V — on demand) ~ 50 Hz
Power supply system Three-phase (Single-phase - on demand)
Power 3,7 kW
Cooling power 7.500 btu
Package overall size 1050 х 650 х 1580 mm
Package weight 200 kg
Warranty period 1 year
The period of tempering 15 min. (max.)

Reviews

Manual

Read the manual before starting work
User's manual
